Passive WiFi probe request analyzer for mobility tracking and social graph inference.
KEYWORDS:
+7
Wintlab is a passive surveillance system that shows how much private information modern devices leak on their own. Phones, tablets, and laptops constantly send out "Probe Requests," small broadcasts asking whether previously saved networks are nearby (for example "Home WiFi" or "Starbucks").
By quietly listening to these requests, Wintlab builds a profile of a device owner without any interaction with them. It runs on a portable #raspberry-pi node and collects enough data to infer travel history, social circles, and even daily habits.
System Architecture
The project has two parts: a field-deployed Physical Device that collects data, and a centralized Backend Server that turns it into a graph.
Physical Device (The Ear)
The collection node is a #raspberry-pi running a stripped-down #arch-linux ARM build. To push the wireless adapter's capture rate as high as possible, the hardware runs past its stock settings.
- •Scanner: handles channel hopping (via
iwconfig) and raw packet capture. - •Daemon: compresses the JSON logs and uploads them to the server.
Loading diagram...
Backend (The Brain)
The backend is a #flask web app sitting on top of a #neo4j graph database. A graph fits the data naturally, since it is all about relationships: Person A is linked to Person B because both visited Location C around Time T.
Loading diagram...
Key Capabilities
Wintlab never decrypts traffic. It only reads what devices announce in the open.
Mobility Tracking
The SSIDs a phone looks for reveal where its owner has been. By cross-referencing WiGLE and Wifimap, an SSID like "Tahin Moda" can be resolved into real GPS coordinates.
- •Result: the system tracked a target's movement and found they regularly visited specific restaurants in the Moda district.
Social Graph Inference
Social links are inferred from co-occurrence and shared networks.
- •Co-occurrence: two MAC addresses repeatedly seen together across different places and times probably belong to people who know each other.
- •Shared History: two strangers who both carry the same private company #wifi in their probe lists are likely colleagues.
Habit & Demographics Profiling
#wifi network names give away surprisingly personal details.
- •Social Habits: a device probing for "Tahin Moda," a falafel place, hints that its owner likes vegetarian food.
- •Language Detection: the character sets and words in SSIDs (for example "Fenerbahce" or "ÖmerEren") are a strong signal of the owner's native language.
Field Results
In a field test around Sabanci University and its surroundings, the prototype captured:
- •381,265 total Probe Requests
- •70,700 unique SSIDs
That was enough to build a rough "Map of Life" for random passersby, and a clear demonstration that leaving #wifi on in Active Discovery Mode is a real privacy risk.
